Boiler Tubes

Tengri Steel Co.,Ltd is a famous China boiler tubes manufacturer and supplier, equipped with a productive factory and company and as a professional boiler tubes exporter and seller, we are always welc...

Product Details

Tengri is one of the leading China boiler tube manufacturers, if you want to buy or import best high-quality boiler tube, please feel free to contact us.

Low-medium boiler tube mainly used for producing low and medium boiler , super-heated steam tube, boiling-water tube , water wall tube, which is suitable for the working temperature less than 450°C and working pressure not more than 5.88Mpa environment. It is normally made by carbon steel in hot rolled or cold drawn. Main applicable standard is GB3087.

High pressure boiler tube mainly used for high pressure and ultrahigh pressure  super-heated tube, reheat tube, gas-guide tube, main steam pipe and so on. The workable working temperature is 450~650°C, working pressure=9.8Mpa.Main applicable standard include GB3087, GB5310, DIN17175, ASME SA-106 , ASME SA-210M, ASME SA-213M, ASME SA355M etc.

Nuclear power tube perform GB5310, ASTM A106, ASTM A335 standard. Mainly used for the normal main steam pipe and water supply pipe.



Type

                                 Size



Standard

Grade



Outside Diameter(MM)

Wall Thickness(MM)




10



GB 3087

20

10

Low-Medium
Pressure Boiler Tube

48~1200

5~30

DIN1629

ST37.0



DIN17175

ST35-8



ST45-8



20G



20MnG



25MnG



GB5310

15MoG



20MoG



15CrMoG



12Cr1MoVG



JIS G3461

STB410



STB510



15Mo3



DIN17175

13CrMo44



10CrMo910



14MoV63

13CrMo4-5



SA106GrA

High Pressure Boiler Tube

48~457

3.91~57

ASMESA106

SA106GrB



SA106GrC



SA210GrA



ASMESA210

SA210GrB



SA210GrC



T2



T11



ASMESA213

T12



T22



T91



P2



P11



ASMESA335

P12



P22



P91



ASMESA335

P11

Nuclear Power Tube

48~711

3.91~57



P22

Related Search: Boiler Tube, Boiler steel pipe, boiler steel tube, boiler steel tubing, boiler pipe.
