Heavy Wall Stainless Steel Tube

 Heavy Wall Stainless Steel Tube







304 / 316L heavy wall stainless steel tube





---

Overview:

304/316L stainless steel thick walled tube, which material is 304/316L stainless steel,

belongs to Molybdenum stainless steels, which performance better than type 304 and 310 stainless steel.

At high temperatures, when the concentration of sulfuric acid less than 15% and more than 85%,

the 316L stainless steels usually should be used widely.

Besides, with a good corrosion chlorides performance,

this grade of stainless steel usually is used in marine environment.





Name: thick-walled inox 316l tube, stainless steel tubing wall thickness

OD(out diameter): 6-830mm

Wall Thickness 0.5-55 mm.

Solution Treatment: 1010~11500

Carbon content: no more than 0.03%

Melting Point: 1375-14500

Details:

Heat Resistance  ---

When indirectly using under 1600? and continuously using under 1700?,

the 316L stainless steel has favorable oxidation resistance.

When heat range 800?-1575?, It is best not to use continuously 316L stainless

steel products. If out of that range, this stainless steel has good heat

resistance with high strength properties.

Heat Treatment  ---

Annealing temperature range 1850? - 2050 ,then quickly cooling.

Please attention, 316L stainless steels can't be hardened through heat treatment.

Welding filler ---

Adopt a standard welding method, can use 316Cb, 316L or 309Cb stainless steel

fillers or welding rods. In order to achieve the optimal anticorrosion, 316

materials welding section need to be treated through annealing, but 316L

materials not need.

heavy wall tube Application  ---

Paper making, heat exchanger, dyeing equipments and conditions, film swilling

machine, Piping assembly, construction outside materials in low-lying and coastal

areas.

Chemical Component  ---

C=0.03   Si=1.00  Mn=2.00  P=0.035  S=0.03  Ni:12.0-15.0   Cr:16.0-18.0

Mo:2.0-3.0

Delivery state --

Annealing with solution treatment



About us

Shaanxi Huitong Special Steel Co., Ltd, locates Xixian new area of Xi'an City,

Shaanxi, China, specialized in producing all kinds dimension of seamless

stainless steel pipe tubing, heavy wall stainless tubing. Also supply stainless

steel sheet, plate, coil, bar, coil and other alloy steels. We have ten years

of producing and selling experiences in China and all over the world.



Shapes: round tube, square pipe, thick wall.

Materials: 201, 301, 304, 304L, 321, inox 316l, 310S, 2520, and so on.

Standards: ASTM A312/A312M,  ASTM A213/A213M,  ASTM A269/269M





---



Heavy wall stainless steel pipe stock list







Remark: nonstandard dimension.

(OD*TNK)



F6×1/1.5     F60×2/3/4/5/6

F8×1/1.5/2     F60×8/10/12/16F140×4/5/6

F10×1/1.5/2     F63×4/5     F140×/8/10/12/15/20

F12×1/1.5/2     F63×8/10/12/16/18F142×18

F14×1.5/2/2.5/3/4F65×4/5/6/8/10/13F145×18

F16×2/2.5/3/3.5/4F68×4/6/8/10/12/15F146×10/12

F18×2/3/4     F70×3/8/10/12     F152×6/8/10/12/14/20

F19×2F70×15/18/20                F159×3/4/4.5/5/6

F20×2/2.5/3/4/5F73×3/4/5     F159×8/10/12/15/20/30

F21×4.5     F73×8/10/12/15/20F168×3/4/4.5/5/6/7

F22×2/2.5/3/4/5/6.5F76×2/3/4/5/6     F168×8/10/12/16/20

F25×1.5/2/2.5/3/4/5/7F76×8/10/12/15/18F175×16

F27×2/2.5/3/4/5/6/8F80×4/6/8/10/12/15/20F180×6/8/10/12/16/30

F28×3/4/6.5     F82×16.5     F185×10/18/25

F30×3/4/5/8/10F83×4/8/10/11/12/15/18F190×9

F32×2/2.5/3/4/4.5/5/6F86×8/10/15/20F194×6/8/10/18

F32×8/9/10     F89×2/3/4/4.5/5/5.5/6F200×14/34

F34×2/3/4/5/6/8/10F89×8/10/12/15/18F203×20

F36×4/6     F92×8/10/12     F205×16/26

F38×2/3/4/5/6/8/10F95×6/8/10/12/16/20F219×4/5/6/8/10

F40×3/4/5/6/8/10F102×4/5/6     F219×12/15/20/25/30

F42×2/3/4/5/6/8/10F102×8/10/13/15/20F230×20

F45×2/2.5/3/3.5/4/5/6F108×2/3/4/4.5/5/6F245×6/8/10

F45×8/10/12     F108×8/10/12/13/15/20F250×26

F48×2/3/3.5/4/5/6F114×2/3/4/5/6F273×4/6/8/10/12/20/34

F48×8/10/12     F114×8/10/12/15/20F325×6/8/10/12/16/18

F50×12     F116×19     F377×8/9/10/15

F51×2/3/4/5/6/8/10/15F121×6/8/10/12/16/20F406×14

F55×8/10     F127×8/10/13/16/20F426×9/10/12

F57×2/3/3.5/4/5/6F133×3/4/5/6     F508×15

F57×8/10/12/16F133×8/10/12/15/18/22



---

Shanghai Tengri Steel Co., Ltd is one of the largest Manufacturer, Supplier, Exporter, Stocker for Angle, Bar, Beam, Coil , Strip , Plate, Sheet ,Wire , Pipe, Tube, Flanges, Fittings in China more than 10 years . Our products have been widely used in Boiler & Heat exchanger, Decoration, Construction, Oil and Chemical industry, Food industry, Pharmaceutical industry, Ship-building and automobile manufacturing, Water transportation systems etc .



Main produce ---

 Angle, Bar, Beam, Coil , Strip , Plate, Sheet ,Wire , Pipe, Tube, Flanges, Fittings etc



Standard involved ---

GB, ASTM ,AISI , AWWA , EN , BS, GOST, DIN , KR , JIS - Custom products is availiable !



Certificates –

BV, SGS , ISO9001, ISO14000, OHSAS18001 , API, DNV, BV, SGS, TUV, ABS, LR, GL, TS,PED etc.



Why Us ?

Most Competitive price , Strictly quality control, Full set of tech data sheet , Project management chart , ITP, Logistics and stock planning ,Experienced staff , Delivery schedule , Package details , High quality products and Excellent service
