603 675 Gy5 Bulletproof Steel Armored Plate

Tengri Steel is a famous China Bulletproof Steel Plates manufacturer and supplier, equipped with a productive factory and company and as a professional 603 675 gy5 bulletproof steel armored plate exporter and seller, we are always welcoming you to buy and wholesale high quality 603 675 gy5 bulletproof steel armored plate from our factory.

 603 675 Gy5 Bulletproof Steel Armored Plate

  We can supply you Minitary armored ballistic steel plates, which produced according to the China protection standard GJB 31A- 2000, means the specification for 30CrMnMoRE, 30CrNi2MnMoRE and 30CrNi3MoV steel plates for armour use.

    Our main armored sheets : Wuyang Steel 603, 675, Gy4, Gy5, and imported PRO500.

1.  Material :  603 ( 30CrMnMoRE)

Standard:  GJB 31A - 2000

Chemical properties :   C ：0.26～0.32    Si ：0.30～0.60     Mn：1.05～1.55

              S ：≤0.025       P ：≤0.020             Cr：0.80～1.30    Mo：0.60～0.80
             RE：0.07～0.12

Smelting Process :   Electric smelting furnace

Heat treatment :   Quenching : 900 - 930 ℃ ,  2 - 3 min/mm , water-cooling ;

                               Annealing: 600-630℃, 3-5 min/mm,  water-cooling.

More infomation, please ask us for the MTC certificate.

2.  Material : Gy5  ( 26SiMnMo )

Chemical Properties

   C ：0.23～0.29     Si：1.20～1.60   Mn：1.20～1.60   P ：≤0.030  S ：≤0.030

     Cr：≤0.30  Ni：≤0.50     Mo：0.15～0.25   Cu：≤0.30

 Smelting Process :   Electric smelting furnace

  Heat treatment :    Quenching : 890 - 910 ℃ , 2 - 3 min/mm , water-cooling ;

                                         Annealing: 390 -410 ℃, 3-5min/mm,  water-cooling .

3.  Material：675 （ 30CrNi3MoV）

Chemical Properties

  C ：0.26～0.32    Si：0.15～0.35    Mn：0.30～0.50    P ：≤0.015
    S ：≤0.010          Cr：0.60～1.00    Ni：2.80～3.20    Mo：0.40～0.50
    RE：0.06～0.13

Smelting Process :   Electric smelting furnace + VHD

Heat treatment : Quenching : 870 - 910 ℃ , 2 - 3 min/mm , water-cooling ;

                                      Annealing:  580 - 620  ℃,  3 - 5 min/mm,  water-cooling .

4. Imported from Sweden armored steel plate : PROTECT 500.

  we used to supply China ordnance factory of military industries these bulletproof sheet.

we can supply you test certificates and military offical certificate if you will place a order

to us.

       You can send your engineer or inspection agent to us.

       You are perfectly welcome any time.

                The protection level of 603, 675 and PRO500

we can produce in any sizes as your customized.

Thickness : 8 - 700 mm

Width: 1500 - 4020 mm

Length: 3000-27000 mm.
